Fanco Infinity-ID DC Ceiling Fan with Wall Control - Black 54"

Fanco Infinity-ID DC Ceiling Fan with Wall Control - Black 54"

Introducing the all new black 54" Infinity-ID complete with a hardwired DC wall controller with 6 selectable speeds. Powered by an improved motor with improved airflow on the high speed and even lower power consumption. Featuring the increasingly popular, minimalistic design with three lightweight ABS blades that elegantly join to create a seamless design.

Please note that the wall controller requires a specific and accurate hole size in the gyprock. Take a look at the fanco recommended installation guide for more information.

As the face of this wall controller is 85mm square, if you are replacing a standard sized wall control you may need to patch the hole or install a blank plate and install this controller next to it. We would recommend discussing with your installing electrician prior to purchasing to determine suitability.

Regular Price $439.00 Special Price $399.00

Infinity-ID DC Features Overview:

Key Features

Install Location: Indoor / Outdoor (Undercover) & Coastal
Blade Material: ABS Plastic
Blade Span: 54" (137cm)
Motor Type: Energy Saving DC Motor
Operation: Hardwired Wall Control
Summer/Winter Use: Not Reversible
Ceiling to Blade Drop: 270mm
Angled Ceilings? Suitable up to 7 degrees
Light: Not available with light & wall control

Other Details:

  • Slimline Scandinavian design powered by a quiet DC motor
  • Larger than average blade span suitable for living areas
  • Flexible in installation with the Infinity-ID suitable for indoor & outdoor (undercover) locations
  • Hardwired DC wall controller
  • Updated construction & materials - all ABS and electroplated metal, making this fan suitable for indoors, outdoors and coastal locations


Performance Data:

1 90 5 4,631 m3/hr
2 112 6.4 5,934 m3/hr
3 135 8.7 6,796 m3/hr
4 157 12 7,298 m3/hr
5 179 16.4 8,743 m3/hr
6 200 23 10,859 m3/hr


Performance Summary

  • A great range of speeds ranging from 90 - 200 RPM
  • Class leading energy efficiency, only 23w on the highest speed
  • Impressive airflow - 10,859 m3/hr on the highest speed.


This model utilises a DC motor, however it has an internal inverter and is therefore compatible with normal AC electrical systems. It cannot be connected directly to a DC power source.

More Information
Motor Type DC
Brand Fanco
Style Modern, Architectural / Designer
Location Indoor, Outdoor - Damp Location (undercover), Outdoor - Coastal Location (limited)
Blade Span (Size) 54" (137cm)
Motor Colour Black
Blade Colour Black
Blade Material Plastic
IP Rating No IP Rating Specified
Blade Pitch Approx 12 degrees
Drop (Ceiling to Blade) 270mm
Number of Blades 3
Airflow (Max) 10,859 m3/hr
RPM (High) 200
RPM (Low) 90
Motor (max) 23w
Reversible (Summer/Winter) Not reversible
Speeds 6 speeds
Voltage 240V - Standard
Suitability for Raked Ceilings Suitable up to 7°
Warranty Details Fanco: 2 year in home repair or replace warranty followed by 3 year repair or replacement warranty for motor only. Conditions apply and labour cost is limited, visit the fanco website for more information.
Warranty Disclaimer ** Enclosed Outdoors: Products installed at least 1.5m from the perimeter of the roof / eaves of the enclosure (for protecting the product from direct or indirect rain water or sunlight)., 1. Ensure installation takes place by a licensed and qualified electrician unless otherwise stated. Proof is often required upon requesting a warranty - this proof will need to be in the form of an invoice or receipt detailing the name and licence. --, 2. Never take down your fan if there is a fault before contacting the warranty line. Most warranties are in-home therefore will only take effect on installed fans unless otherwise instructed. --, 3. You must maintain your ceiling fan to prevent corrosion damage to the finishes. A lack of maintenance causing damage is not covered by warranty. See your fan instructions for care / maintenance instructions. --
Installation Disclaimer 1. All electrical goods require installation from a licensed electrician. Please wait for your goods to arrive before booking your electrician. It is important that you keep your electrician's certificate of installation in a safe place. --, 2. Ceiling fans should be installed so you have a minimum of 2.1m from blade to floor, however please check with your local council regulations and electrician to assess your individual needs. --
